Attaching and Removing a Lens
33
a
• Lens calibration helps the projector to correctly acquire the
lens position and adjustment range, and takes up to 100
seconds. When calibration is finished, the lens returns to the
same position it was in before calibration.
The following lenses return to the standard position.
• ELPLX01/01S
• ELPLX01W/01WS
• ELPLX02/02S
• ELPLX02W/02WS
• If no message is displayed after attaching the lens, perform lens
calibration using one of the following methods.
• Hold down the [Default] button on the remote control for
approximately 3 seconds.
• Change the projector's menu:
s Extended > Operation > Lens Calibration
• If you do not calibrate the lens, the following functions may
not operate correctly.
• Focus
• Distortion
• Zoom
• Lens Shift
• Memory (Lens Position)
Attention
If the icon indicating that lens calibration has failed is displayed, remove the
lens and then reinstall it. If the message continues to be displayed, stop
using the projector, remove the power plug from the electrical outlet, and
contact Epson for help.
j
When using one of the following lenses, select the Lens Type in the
projector's menu according to the lens you are using so that distortion
correction is performed correctly.
• ELPLS04
• ELPLU02
• ELPLR04
• ELPLW04
• ELPLM06/ELPLM07
• ELPLL07
s Extended > Operation > Advanced > Lens Type
a
If you are projecting from a table or other flat surface, the image may
be tilted depending on your lens. Adjust the tilt of the image using the
front and rear feet.
Removing a Lens
You can remove a lens to replace it with a different lens.
Caution
Wait at least 30 minutes to remove or replace the lens after turning off the
projector. Touching the lens unit before it cools down may cause burns.
a
The projector uses a laser as the light source. As a safety measure, the
light source turns off when the lens is removed. Attach the lens, and
then press the [On] button to turn it back on.
a
Hold down the [Lens Shift] (remote control) or [Lens] (control panel)
button for approximately 3 seconds to move the lens to the home
position.
b
Turn off the projector and unplug the power cord.
