Signal Menu
77
You can change the projected image ratio to make the edges visible by a
selectable percentage or automatically.
a
Setting is only displayed when the input signal is component signal.
Blanking
s Signal > Blanking
You can hide images in the specified area.
Use the arrow buttons on the control panel or remote control to adjust the
area. You can hide up to half of the projected image in each direction (except
for one pixel).
a
Setting is only displayed when the Content Playback setting is set to
Off in the projector's Settings menu.
Color Space
s Signal > Color Space
You can switch the color space that can handle the color information of the
input image.
Select Auto to apply a suitable color space for the AVI InfoFrame of the
image.
a
Setting is only displayed in the following cases.
The current source is HDMI, HDBaseT, DVI-D, or SDI
(EBPU2010B/EBPU2010W).
Color Mode is set to other than BT.709 or DICOM SIM.
Dynamic Range
s Signal > Dynamic Range
You can set the video range to match the setting of input source.
Select Auto to automatically identify the dynamic range of the input signal.
The result for your selected setting is displayed as Signal Status.
HDR10 Setting
You can adjust the PQ curve of the dynamic range in the HDR PQ
(Perceptual Quantizer) method.
HLG Setting
You can adjust the HLG curve of the dynamic range in the HDR HLG
(Hybrid Log Gamma) method.
a
Setting is only displayed in the following cases.
The current source is HDMI, HDBaseT, or SDI
(EBPU2010B/EBPU2010W).
Color Mode is set to other than BT.709 or DICOM SIM.
HDR10 Setting is only available when Signal Status is set to
HDR10.
HLG Setting is only available when Signal Status is set to HLG.
Video Range
s Signal > Advanced > Video Range
You can set the video range to match the setting of input source from the
HDMI, DVI-D, or HDBaseT port.
Limited (16-235)
For the brightness range 16 to 235.
Full (0-255)
For the brightness range 0 to 255.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Epson EB-PU2010B and is the answer not in the manual?

Epson EB-PU2010B Specifications

General IconGeneral
Matrix size1.03 \
Heat dissipation1819 BTU/h
Number of colors1.07 billion colors
Native aspect ratio16:10
Projection technology3LCD
Contrast ratio (typical)2000:1
Screen size compatibility- \
Projector native resolutionWUXGA (1920x1200)
Keystone correction, vertical-45 - 45 °
Keystone correction, horizontal-30 - 30 °
Projector brightness (economic mode)7000 ANSI lumens
Light source typeLaser
Service life of light source20000 h
Service life of light source (economic mode)30000 h
Throw ratio0.35 - 7.41:1
Focal length rangevaries by lens mm
Interchangeable lensYes
3DNo
Video processing10 bit
Video color modesCinema, Dynamic, Natural, Presentation, DICOM simulation mode, Multi-projection, BT.709
Analog signal format systemNot supported
Serial interface typeRS-232C
USB 2.0 ports quantity2
Noise level37 dB
Preset modesCinema, Presentation, Dynamic
Country of originPhilippines
Noise level (economic mode)30 dB
PlacementCeiling, Desktop, Flying frame
Product typeLarge venue projector
Product colorBlack
Market positioningBusiness
Cable lock slot typeKensington
Power sourceAC
AC input voltage100-240 V
AC input frequency50 - 60 Hz
Power consumption (standby)0.5 W
Power consumption (typical)535 W
Power consumption (economy mode)452 W
Storage temperature (T-T)-10 - 60 °C
Storage relative humidity (H-H)10 - 90 %
Operating relative humidity (H-H)20 - 80 %
Bundled softwareInhalt DIY-App, EasyMP Multi PC Projection, Epson Projektor Content Manager, Epson Projektor Management, Epson Projektor Professional Tool
Supported network protocolsHTTPS, IPv6, SNMP, ESC/VP.net, PJLink
Software supportvia: Crestron Integrated Partner, Extron IP Link, Extron XTP, AMX Device Discovery
Pallet weight0 g
Quantity per pack1 pc(s)
Quantity per pallet14 pc(s)
Harmonized System (HS) code85286200
Weight and Dimensions IconWeight and Dimensions
Depth436 mm
Width545 mm
Height189 mm
Weight16800 g
Package depth765 mm
Package width570 mm
Package height270 mm
Package weight21876 g
