Extended Menu
97
Top Edge/Bottom Edge/Right Edge/Left Edge
Select the edge you want to blend on each projector.
• Blending to turn on the Edge Blending feature for the selected edge.
Gradation is applied to the blending range.
• Blend Start Position to adjust the point where edge blending begins in 1
pixel increments. The blending start position is displayed with a red line.
• Blend Range to select the width of the blended area in 1 pixel
increments. You can select up to 45% of the projector's resolution.
• Blend Curve to select a gradient for the shaded area on the projected
image.
Line Guide
Set to On to display a guide on the blended area.
Pattern Guide
Set to On to display a grid to match the blended area.
Guide Color
Select a combination of guide colors.
a
Set the Color Mode setting to Multi-Projection in the projector's
Image menu for all of the projectors.
Black Level
s Extended > Multi-Projection > Black Level
s Extended > Multi-Projection > Screen Matching > Black Level
You can adjust the brightness and tone differences in overlapping images.
Color Adjustment
You can adjust the brightness and tone of the areas. The adjustment areas
are displayed based on the Edge Blending setting.
When multiple screens are overlapping, adjust overlapping areas starting
with the brightest areas first. Adjust the non-overlapping area (darkest
part) last.
Area Correction
If the tone for some areas does not match, you can adjust it individually.
Reset
You can reset all adjustment values on the Black Level menu to their
default settings.
a
• You cannot adjust the Black Level setting when a test pattern is
displayed.
• If the Geometry Correction value is very large, you may not be able
to adjust the Black Level correctly.
• The brightness and tone may differ in areas where the images overlap
as well as in other areas even after performing Black Level
adjustment.
• If you change the Edge Blending setting, the Black Level setting
returns to its default value.
• Available only when at least one of Top Edge, Bottom Edge, Left
Edge, and Right Edge are set to On in the Edge Blending settings.
Reset (Multi-Projection menu)
s Extended > Multi-Projection > Reset
You can reset all adjustment values on the Multi-Projection menu to their
default settings.
Screen Matching
s Extended > Multi-Projection > Screen Matching
You can adjust the tint, brightness, black level, and blend curve of multiple
projectors so that they match better.
If your projectors are on a network, the brightness and tint for multiple
projectors are corrected automatically based on the darkest projector.
