Projector Parts and Functions
15
Name Function
E
Cable holder Pass a commercially available cable tie through here to
secure cables.
Warning
Do not bundle the power cord to the other
cables. Otherwise, a fire may occur.
F
SDI Out/In ports
(BNC)
(EB‑PU2010B/EB‑PU2010W only)
Inputs video signals from SDI compatible video
equipment.
Outputs video signals input from the SDI In port to an
external monitor.
You can connect two projectors in a chain using a SDI
cable.
If you want to output images to an external monitor
when the projector is turned off, select Always On as
the A/V Output setting in the projector's Extended
menu.
s Extended > A/V Settings > A/V Output
G
Service port
(USB connector Type
B)
This port is used for batch settings and firmware
update.
H
USB-A port
(USB connector Type
A)
Use to connect a USB memory device for projecting
movies or images in Content Playback mode.
Use to connect the optional camera.
Provides a connection for a streaming media player to
power it.
Attention
• Use the USB cable supplied with or specified
for use with the device.
• Do not connect a USB hub or a USB cable
longer than 3 meters, or the device may not
operate correctly.
Name Function
I
HDMI port
(HDMI)
Inputs video signals from HDMI compatible video
equipment and computers.
Connects the optional base unit.
This port is compatible with HDCP2.3. (Audio is only
supported by PCM)
J
DVI-D port
(DVI-D 24-pin
single)
Inputs the computer DVI-D signals.
This port is compatible with HDCP1.4.
K
HDBaseT port
(RJ-45)
Use to connect a LAN cable to the optional HDBaseT
Transmitter. You can use a network cable up to 100 m
in length. To ensure proper data transmission, use a
Category 5e STP cable or better. However, operation is
not guaranteed for all input/output devices and
environments.
This port is compatible with HDCP2.3.
Check the following settings:
• To enable communication from the Ethernet and
serial ports on the transmitter, select On as the
Control Communications setting in the projector's
Extended menu.
s Extended > HDBaseT > Control
Communications
• If you have connected an Extron XTP transmitter or
switcher, select On as the Extron XTP setting in the
projector's Extended menu.
s Extended > HDBaseT > Extron XTP
L
LAN port
(RJ-45)
Use to connect a LAN cable to connect to a network.
Use a 100Base-TX or 10Base-T network cable.
To ensure proper data transmission, use a Category 5
shielded cable or better.
To Next Page
