311
SDI-In
Mode Resolution (dot)
V Sync
(Hz)
SDI
YCbCr
4:2:2
8 10 12
SD-SDI (NTSC) 720 480 59.94 ü
SD-SDI (PAL) 720 576 50 ü
HD-SDI (720p)_50 1280 720 50 ü
HD-SDI (720p)_59.94 1280 720 59.94 ü
HD-SDI (720p)_60 1280 720 60 ü
HD-SDI (1080p)_50 1920 1080 50 ü
HD-SDI (1080p)_59.94 1920 1080 59.94 ü
HD-SDI (1080p)_60 1920 1080 60 ü
HD-SDI (1080p)_23.98 1920 1080 23.98 ü
HD-SDI (1080p)_24 1920 1080 24 ü
HD-SDI (1080p)_25 1920 1080 25 ü
HD-SDI (1080p)_29.97 1920 1080 29.97 ü
HD-SDI (1080p)_30 1920 1080 30 ü
3G-SDI (1080p)_50 * 1920 1080 50 ü
3G-SDI (1080p)_59.94* 1920 1080 59.94 ü
3G-SDI (1080p)_60 * 1920 1080 60 ü
* 3G-SDI only supports Level A.
