Installing the Touch Unit
101
c
Select Installation Pattern
You see the installation pattern on the projected image.
d
When installing on a magnetic surface, check the installation position and attach the touch
unit with magnets
When installing on a non-magnetic surface, go to the next step.
Caution
Powerful magnets are used which can cause injury if you trap your fingers. Be careful not to trap
your fingers or any other part of your body between the magnets and the installation surface.
5.7-50mm
(20 - 50mm (16:6, 21:9))
After you attach the Touch Unit, go to "Turning on the Touch Unit" p.109.
To Next Page
