Installing the Touch Unit
102
e
When installing on a non-magnetic surface, attach the template sheet to the Touch Unit
installation position
As shown below, attach the bottom of the template sheet onto the installation pattern.
f
Drill holes in the installation surface, and then remove the template sheet
g
Attach the spacers supplied (x2) to the screw holes on the back of the Touch Unit
h
Remove the rubber caps (x2) from the front of the Touch Unit
To Next Page
