24
4 Numeric buttons
5 Auto button (automatically adjusts position, tracking, and sync settings when projecting analog
RGB signals from the Computer ports)
6 Num button (when held down, switches numeric buttons to number function)
7 Menu button (accesses projector menu system)
8 Arrow buttons (move through on-screen options)
9 Enter button (selects options)
10 User button (customizable for different functions)
11 Color Mode button (selects display modes)
12 Aspect button (selects the image aspect ratio)
13 E-Zoom +/- buttons (zoom into and out of the image)
14 A/V Mute button (turns off picture and sound)
15 Split button (splits the screen between up to four image sources)
16
Home button (accesses projector Home screen)
17 Freeze button (stops video action)
18 Volume up/down buttons (adjust speaker volume)
19 Default button (returns the current setting to its default)
20 Esc button (cancels/exits functions)
21 ID button (selects a projector to use with the remote control)
22 LAN button (connects to a network source)
23 USB button (cycles between USB Display and USB-A port)
24 Source Search button (searches for connected video sources)
25 Remote control emitter
Parent topic: Projector Part Locations
