Disassembly and Assembly
Arranging the Cables
When you assemble the printer, arrange the cables as shown in Figure 4-22.
El
-
-
Printer Mechanism
(Bottom)
W
Figure 4-22. Arranging the Cables
Epson FX-8700170
4-21
