Epson FX-870 Service Manual

Printer Features
Safety Approvals
Safety standards
UL1950 with D3
CSA!z2.2#220
RF1 *
FCC class B
Firmware Specifications
Print Control
Printing direction
Text mode
Bidirectional printing with logic seeking.
(Unidirectional printing can be specified by software.)
Bit image mode Unidirectional printing
Character sets ASCII characters
ESC/P mode -
Italic, PC 437,850,860,863, 865, BRASCII, Abicomp
IBM mode -
PC 473,865 (PC = Personal Computer character table )
Fonts:
Draft, NLQ Roman, NLQ Sans serif
Table l-10. Character Size and Pitch
Type of letters
Pica
Condensed
Width
Height
[mm1
[mm1
2.1 3.1
1.05 3.1
Character pitch
[mm1
2.54 (10 cpi)
1.48 (17 cpi)
Elite
1.7
3.1 2.11‘ (12 cpi)
Condensed elite
0.85
3.1 1.27 (20 cpi)
Table l-11. Printable Columns
Type of letters
Printable columns [cpi]
80-column model
136-column model
Pica
80
136
Condensed
137
233
Elite
96
163
Condensed elite
160 272
-
1-12
Epson FX-8700170
