Epson FX-870 Service Manual

Adjustments, Maintenance, and Lubrication
Table 5-2. Lubrication Points
Ref. No. Lubrication Points Lubricant
1 Platen gap adjustment slots on the left frame (excluding G-26
the two slots at the bottom)
2 The arms and tab of the RD assembly
G-26
d
3 The shaft end of the drive roller assembly
G-26
4 The ribbon drive gear train
G-26
5 The oil pad in the carriage assembly
o-2
6 The cam surface of the tractor clutch cam
G-26
7
The cam end of spur gear 34.5
G-26
-
5-6
Epson FX-870/1170
