Disassembly
and Assembly
Assembly Note
‘-
When attaching the timing belt to the carriage assembly, secure the timing belt using
the
1eR
and right clips of the carriage assembly as shown below. Make sure there is no slack
in the timing belt.
Clip
Timing
Figure 4-16. Attaching the Timing Belt
4-16
Epson
FX-870/1170
-
