a.
Connect the small end of the main cable to the projector’s
Mouse/Corn 1 port. (Use the Mouse/Corn 2 port if you are
connecting a second computer.)
b. Connect one end of the
Ps/2
mouse cable included with the
projector to the mouse terminal on the square end of the main
cable.
c. Disconnect the computer’s Ps/2 mouse cable from the mouse
port on the back of your computer and replace it with the
other end of the mouse Ps/2 mouse cable included with the
projector.
d.
If
your system uses a serial mouse, perform steps b and c using
the serial mouse cable instead of the Ps/2 mouse cable (not
shown in the illustration).
e.
To configure the projector from your PC using the
ELP Link
II
software or to use the Effects buttons on the
remote control, connect one end of the serial cable to the serial
terminal on the square end of the main cable.
f. Connect the other end of the serial cable to the serial port on
the back of your computer.
Note: You will not be able to use ELP Link II software if your
system has only one serial port that is being used to support a
serial mouse.
g.
Tighten the screws on all connectors to make sure they are fas-
tened securely.
1 l Installation
