Setting Effect Options
Once you have assigned functions to one or more Effects buttons, you
can specify detailed options for each function.
To set detailed options, click Detail Setting. A dialog box similar to
the following appears. (The options and tabs displayed depend on
which functions are currently assigned to the Effects buttons.)
Click the tab for the function you want to adjust, then make any
settings you wish.
To test each setting, click the Test button and then click the left mouse
button to start and stop each setting. To end the test, click the right
mouse button. (If you are using the remote control as a mouse pointer,
use the bottom and top multi-purpose buttons, respectively.)
To save the changes, click OK.
The table on the following page describes the available options for each
function.
4 l Using the ELP Link II Software
