Maintenance 13. Maintenance Parts List

196 S5 Rev.5

Part Name Code Note Ref. Maintenance

Oil Seal

For motor

shafts

For Joint #1

R13B031256

2.2.4

For

Reduction

Gear Unit

For Joint #2

R13B031258

R13B031264

For Cleanroom-model

2.2.5

For Joint #5

R13B031260

R13B031266

For Cleanroom-model

For rotator

For Joint #1

R13B031257

2.2.4

For Joint #2

R13B031259

R13B031265

For Cleanroom-model

2.2.5

For Joint #5

R13B031261

R13B031267

For Cleanroom-model

For Joint #6

R13B031262

R13B031268

For Cleanroom-model

O-ring

For Joint #1

R13B031255

4.2

For Joint #6

R13B031263

Gasket

Base

R13B031269

For Cleanroom-model

R13B031275

2.5

Arm #1 R13B031270

For Cleanroom-model

3.1

Arm #2

S5-A701C* R13B031271

For Cleanroom-model

3.2

S5-A901C* R13B031272

For Cleanroom-model

Arm #3 R13B031273

For Cleanroom-model

3.3

Arm #4 R13B031274

For Cleanroom-model

3.4

Radiating sheet For Joint #1, #2, #3

R13B031910

5.1, 6.1

Battery for backing up motor encoder *2

R13B060006

Lithium battery

ER6V LY

(TOSHIBA)

Joints #5, #6 Unit (Motor NOT included)

R13B080204

Arm #4 is included

Brake Release Unit

R12B120803

For Europe

Setup & Operation

1.5

R12B120804

For USA and Japan
