Maintenance 2. Periodic Inspection
S5 Rev.5 79
Grease Gun Lubrication Nozzle Shape
Use a commercially available grease gun.
We recommend the use of a grease gun with a nozzle shaped like that shown in the figure
below and an outer diameter (øD) 13 mm or less.
Straight
Chuck
Hose
øD
øD
øD
