Epson RC700 Series Maintenance Manual

Maintenance 2. Regular Maintenance Inspection
RC700 Series Maintenance Rev.3 5
2. Regular Maintenance Inspection
Performing regular maintenance inspection properly is essential for preventing trouble and
maintaining safety. This chapter describes the schedules for maintenance inspection and
procedures.
Be sure to perform the maintenance inspections in accordance with the schedules.
You will need following tools for maintenance inspection.
Phillips screwdriver
Slotted head screwdriver
Nut driver
Nipper
Tester
2.1 Inspection Point and Frequency
Inspection Point
Frequency
Method
Check Item
Controller 12 months
Turn ON/OFF motor and
Restart
Activates without any error
E
mergency Stop
Button
12 months
When the motor turned on,
activate the emergency stop
button
Turns off the motor
Safeguard 12 months
When the motor turned on,
turn on the safeguard
Turns off the motor
Fan Filter
1 months
Visual inspection and cleaning
No stain
Fan (Front)
1 months
Checking the operating sound
No noise
Fan (Rear)
1 months
Checking the operating sound
No noise
Battery
12 months
Visual inspection of seven-
segment and LED
No alarm occurred
2.2 Timing of Replacement
Part Frequency Parts Code
Working Time
(Rough)
Reference
Fan Filter
4 years or deteriorated
2195106
5 min.
8.1 Fan Filter
Fan (Front)
Error 515 occurred or noise
2157260
20 min.
8.2.1 Front Fan
Fan (Rear) Error 515 occurred or noise
2157260
15 min.
8.2.2 Fan 2
(only RC700-A)
Battery
Every 5 years or error 511
occurred
2113554
5 min. 8.3 Battery

Epson RC700 Series Specifications

General

Model	RC700 series
Category	Controller
Programming Language	SPEL+
Safety Standard	ISO 10218-1
Type	Robot Controller
Communication Interface	Ethernet, RS-232, USB
Operating Temperature	0°C to 45°C (32°F to 113°F)
Humidity	20% to 80% (non-condensing)
Number of controllable robots	4
