8.5 MDB
MDB
identification
method
There are types of the
MDB and it can be identified by “Assy. No.” or “MDB type”
printed
on the board.
Assy.No.
MDB type
Control Unit
Drive Unit
Manipulator
Joint #1, #2 Joint #3, #4 Joint #5, #6
Remarks
RC700
RC700DU
C4
15A/15A
10A/10A
MDB type
2149935**
2171247**
2145517**
2157372**
2172039**
Assy. No.
RC700-A
RC700DU-A
C4
15A/15A-2
10A/10A
MDB type
2166640**
2171936**
2172974**
2175538**
2194708**
2168582**
2194709**
2145517**
2157372**
2172973**
2175537**
2195535**
2172039**
2195537**
Assy. No.
RC700-A
RC700DU-A
C8
C12 *
50A/30A
15A/15A-2
10A/10A
MDB type
2169285**
2205667**
2205668**
2166640**
2171936**
2194708**
2194709**
2145517**
2157372**
2195535**
2195537**
Assy. No.
* No support for Drive Unit
Control Unit
Drive Unit
Manipulator
Joint #1, #5 Joint #3, #4 Joint #2, #6
Remarks
RC700-A
RC700DU-A
N2 *
5A/5A
MDB type
2175610**
2176557**
Assy. No.
N6
30A/5A
15A/5A
30A/5A
MDB type
2186906**
2188814**
2186907**
2188815**
2186906**
2188814**
Assy. No.
* No support for Drive Unit
