Epson RC700 Series Maintenance Manual

Maintenance 8. Maintenance Parts Replacement Procedures
RC700 Series Maintenance Rev.3 63
DMB
-Sub Board
Installation
(1)
Mount the plate
that secures the connectors on the front side to the DMB-
SUB board.
(2)
Mount the DMB
-SUB Board to the DMB. (Mounting screws ×3)
(3)
Connect the cables to the DMB
-SUB Board.
(4)
Mount the Top Panel. (Mounting screw
×6)
(5)
Set
the Encoder Voltage Adjustment Switch.
Set the Encoder Voltage Adjustment Switch according to the length of the M/C cable.
Switch
Length of M/C Cable
1
3 m
2
5 m
3
10 m
4
15, 20 m
(6)
Connect the power plug
. Turn ON the Controller and make sure that the Controller
starts properly without any vibration or abnormal noise.

Epson RC700 Series Specifications

General

Model	RC700 series
Category	Controller
Programming Language	SPEL+
Safety Standard	ISO 10218-1
Type	Robot Controller
Communication Interface	Ethernet, RS-232, USB
Operating Temperature	0°C to 45°C (32°F to 113°F)
Humidity	20% to 80% (non-condensing)
Number of controllable robots	4
