Epson SC-S30600 Series User Manual

SC-S30600 Series Revision B
ADJUSTMENT Overview 201
Confidential
CR related
parts/units
CR Motor
Replacement 1
p. 134
After
replacement
2 Turn the power on in Serviceman mode. ---

---
3 Reset the motor counter.

--- p. 229
4 Turn the power off. ---

---
5 Turn the power on in normal mode. ---

6 CR Belt Tension Check

Tensimeter U-507

p. 233
7 CR Motor Measurement & Automatic Adjustment

p. 274
8 CR Active Damper Adjustment (Automatic)

p. 240
9 Ink Mark Sensor check & auto adjustment

3M IJ40-10R

p. 238
10 Auto Uni-d adjustment

3M IJ40-10R

p. 241
11 Auto Bi-d adjustment

3M IJ40-10R

p. 242
CR Scale
Replacement 1
p. 130
After
replacement
2 Turn the power on in Serviceman mode. ---

3 Reset the CR Encoder Scale counter.

--- p. 229
4 CR Scale Check

p. 239
CR Timing Belt
Replacement 1
p. 132
After
replacement
2 Turn the power on in normal mode. ---

3 CR Belt Tension Check

Tensimeter U-507

p. 233
4 CR Active Damper Adjustment (Automatic)

p. 240
5 Ink Mark Sensor check & auto adjustment

3M IJ40-10R

p. 238
6 Auto Uni-d adjustment

3M IJ40-10R

p. 241
7 Auto Bi-d adjustment

3M IJ40-10R

p. 242
Table 4-1. Adjustment items and the order by repaired part
Class
Replaced or Repaired
(Reattached) Part/Unit
Required Operations
Service
Program
Jig Media Replaced Reattached Page
