SC-S30600 Series Revision B
ADJUSTMENT Overview 204
Confidential
CR related
parts/units
Print Head
Before
replacement
1 Turn the power on in normal mode. ---
---
2 Dispose of waste ink. ---
---
3 Reset the waste ink counter (Maintenance menu) ---
---
4 Turn the power off. ---
---
5 Turn the power on in Serviceman mode. ---
6 Ink eject
--- p. 257
7
Tube inner cleaning
(Cleaning liquid is primed)
Cleaning cartridge
--- p. 258
8 Tube inner pressure reduction
p. 245
9 Auto CR unlock & move CR to full column side
Replacement 10 p. 121
After
replacement
11 Turn the power on in Serviceman mode. ---
---
12 Reset the Print Head Counter.
--- p. 229
13 Head ID Input
--- p. 246
14 PG Adjustment --- Thickness gauge
p. 243
15 Turn the power on in Serviceman mode. ---
16 Cleaning liquid eject
--- p. 257
17 Initial ink charge
--- p. 259
18 Choke cleaning
--- p. 250
19 Nozzle Check
3M IJ40-10R
p. 248
20 Head inclination auto adjustment (CR direction)
3M IJ40-10R
p. 251
21 Head slant auto adjustment (PF direction)
3M IJ40-10R
p. 254
22 Auto Uni-d adjustment
3M IJ40-10R
p. 241
23 Auto Bi-d adjustment
3M IJ40-10R
p. 242
Table 4-1. Adjustment items and the order by repaired part
Class
Replaced or Repaired
(Reattached) Part/Unit
Required Operations
Service
Program
Jig Media Replaced Reattached Page
To Next Page
