ADJUSTMENT Overview 205
Confidential
Ink supply
related parts/
units
Pump Cap Unit
Replacement 1 p. 141
After
replacement
2 Turn the power on in Serviceman mode. ---

3 Reset the unit counter.

--- p. 229
4 Main Unit Measurement & Automatic Adjustment

p. 274
IC Holder
Before
replacement
1 Turn the power on in Serviceman mode. ---

2 Ink eject

p. 257
3 Reset the IC Holder counter.

--- p. 229
Replacement 4 p. 143
After
replacement
5 Turn the power on in Serviceman mode. ---

6 Initial ink charge

p. 259
7 Nozzle Check

3M IJ40-10R

p. 248
8 CL1 or CL2 cleaning

p. 250
Ink Tube
Before
replacement
1 Turn the power on in Serviceman mode. ---

2 Ink eject

p. 257
3 Reset the tube counter.

--- p. 229
4 Auto CR unlock & move CR to full column side

Replacement 5 p. 147
After
replacement
6 Turn the power on in Serviceman mode. ---

7 Initial ink charge

p. 259
8 Nozzle Check

3M IJ40-10R

p. 248
9 CL1 or CL2 cleaning

p. 250
Table 4-1. Adjustment items and the order by repaired part
Class
Replaced or Repaired
(Reattached) Part/Unit
Required Operations
Service
Program
Jig Media Replaced Reattached Page
