Epson SC-S30600 Series User Manual

SC-S30600 Series Revision B
PRODUCT DESCRIPTION Control Panel 24
Confidential
Media Setup
Customize
Settings
1 to 30 (Media
setting bank)
Head Alignment
Auto (Uni-D) When granular images or blurring appear on the printed result, perform Gap
Adjustment to adjust the Print Head misalignment during printing with this
function.
Auto Adjustment: Reads the adjustment patterns with the sensor during
printing and adjusts it automatically.
Manual Adjustment: Check the printed adjustment patterns visually and
adjust it by entering the best adjustment values.
Auto (Bi-D)
Manual (Uni-D)
Manual (Bi-D)
Heating & Drying
Heater
Temperature
 Pre-heater/platen
heater: 30°C to
50°C (86°F to
122°F)
 After heater: 30°C
to 55°C (86°F to
131°F)
The temperatures for the pre-, platen, and after heaters can each be adjusted
separately.
Drying Time Per
Pass
0 to 10 sec
Sets a time period to pause the Print Head movement for drying the ink
between 0.0 to 10.0 seconds. Depending on the media type and density,
drying ink may take longer. When leaked ink or ink smear appears on the
printed result, set the drying time longer.
After Heater Feed
Mode 1 To feed media to the after heater after printing, choose [Mode 1] or [Mode 2];
otherwise, choose [Off].
If [Mode 1] is selected, the portion fed for drying will not be rewound before
the next job starts. Select this option if the media will be cut before the next
job starts.
If [Mode 2] is selected, the portion fed for drying will be rewound before the
next job starts, eliminating unnecessary margin. Select this option if multiple
jobs will be printed consecutively.
Mode 2
Off
Additional Dryer
On Select [On] to enable, or [Off] to disable, the optional additional print drying
system. Note that even when [On] is selected, the additional print drying
system will turn off with the heaters when the Heat Off Timer expires. The
additional print drying system will turn back on when the heaters resume
operation.
This item is displayed only when the optional additional print drying system is
installed.
Off
Media Suction 0 to 10
Suction is required to maintain the correct distance between the media and the
print head; the amount needed varies with the type of media. Excessive
suction can increase the gap between the print head and thin or flexible media,
potentially reducing print quality or preventing the media feeding normally. In
such cases, you will need to lower media suction. The suction power is
weakened when the parameter is lowered.
Menu Menu Item/Setting Values (shaded one is the default) Explanation
