SC-S30600 Series Revision B
PRODUCT DESCRIPTION Control Panel 28
Confidential
Printer Setup
Heat Off Timer 15 - 240 min
Turns to the sleep mode automatically when no error is occurring, no print job
receiving or there are no operations on the control panel. In this setting, sets
the time to turn to the sleep mode automatically. When the printer turns to the
sleep mode, the screen display on the control panel disappears, and all Heaters
and internal motors turn off to reduce power consumption. When the optional
additional dryer is installed, the fan stops in the sleep mode. Button operations
on the control panel (except [P] button) recovers the screen display on the
control panel. However, when there are no operations in this condition, the
screen display disappears again in about 30 seconds. The printer wakes from
the sleep mode completely and recovers normally, only when the operation
with a hardware operation is executed such as receiving a print job or
operating the Media Set Lever.
Restore Settings
Yes
When this is set to [Yes], returns the set values in [Printer Setup] menus to
their factory default.
No
Maintenance
Nozzle Check Print
Prints the check patterns. Check them visually and execute head cleaning
when blurring or space can be seen.
Cleaning
All Nozzles
Execute (Light),
Execute (Medium),
Execute (Heavy)
Checks the pattern numbers which blurring or space can be seen in their check
patterns. Selects all lines or the nozzle lines including the numbers, then
executes head cleaning. When this is set to [All Nozzles], executes head
cleaning for all nozzles. When [Selected Nozzles] is selected, selects nozzle
lines and executes head cleaning only for them. Select the cleaning level from
[Execute (Light)], [Execute (Medium)] or [Execute (Heavy)]. Select [Execute
(Light)] at first. When blurring or space can be seen even though [Execute
(Light)] is executed, select [Execute (Medium)]. When blurring or space can
be seen even though [Execute (Medium)] is executed, select [Execute
(Heavy)].
Selected Nozzles
C1/M1
Execute (Light),
Execute (Medium),
Execute (Heavy)
Y1/BK1
BK2/Y2
M2/C2
All Nozzles
Head Washing
C1/M1 Washes the Print Head when clogging of the nozzles is not removed even
though continuous head cleaning is executed several times. When this is set to
[All Nozzles], executes head washing for all nozzles. When you know the
pattern numbers which blurring or space can be seen in their check patterns,
select the nozzle lines including the numbers. Head Washing is executed for
the selected nozzle lines only. Cleaning cartridges which are sold separately
are required for Head Washing. The required number of the cartridges is;
All nozzles: 4 cartridges
Selected nozzles: 2 cartridges
Y1/BK1
BK2/Y2
M2/C2
All Nozzles
Menu Menu Item/Setting Values (shaded one is the default) Explanation
To Next Page
