TROUBLE SHOOTING Remedies for Service Call Error 48
Confidential
1934
Pre Heater
power supply abnormal
error 1
Cable disconnection, breaking, blowout of a fuse, or
heater failure.
1. Is the cable connected properly?
2. Is the Sub-E Board out of order?
3. Is the Pre Heater out of order?
1. Reconnect the cable.
2. Replace the cable.
3. Replace the Sub-E Board. (Page 115)
4. Replace the Pre Heater. (Page 171)
1935
HTC
common power supply
abnormal error 2
Abnormal temperature (the heater is not heated).
1. Is the thermistor disconnected?
2. Is the Sub-E Board out of order?
1. Reconnect the thermistor.
2. Replace the Sub-E Board. (Page 115)
1940
Platen Heater
AD abnormal error
A thermistor temperature out of a predetermined
range was detected the predetermined number of
times in a row.
1. Is the thermistor out of order?
2. Is there any disconnected connectors or damaged
cables?
1. Replace the thermistor (Platen Heater). (Page
172)
2. Replace the Main Board. (Page 107)
1942
Platen Heater
overheat error
A heater temperature out of a predetermined range
was detected the predetermined number of times in a
row.
1. Is the thermistor out of order?
2. Is there any disconnected connectors or damaged
cables?
1. Replace the thermistor (Platen Heater). (Page
172)
2. Replace the Platen Heater. (Page 172)
3. Replace the Main Board. (Page 107)
1943
Platen Heater
heat deviation error
The difference between the current temperature and
target temperature exceeded a predetermined limit.
1. Is the thermistor out of order?
2. Is there any disconnected connectors or damaged
cables?
1. Replace the thermistor (Platen Heater). (Page
172)
2. Replace the Platen Heater. (Page 172)
3. Replace the Main Board. (Page 107)
1944
Platen Heater
power supply abnormal
error 1
Cable disconnection, breaking, blowout of a fuse, or
heater failure.
1. Is the cable connected properly?
2. Is the Sub-E Board out of order?
3. Is the Platen Heater out of order?
1. Reconnect the cable.
2. Replace the cable.
3. Replace the Sub-E Board. (Page 115)
4. Replace the Platen Heater.
1950
After Heater
AD abnormal error
A thermistor temperature out of a predetermined
range was detected the predetermined number of
times in a row.
1. Is the thermistor out of order?
2. Is there any disconnected connectors or damaged
cables?
1. Replace the thermistor (After Heater).
(Page 174)
2. Replace the Main Board. (Page 107)
1952
After Heater
overheat error
A heater temperature out of a predetermined range
was detected the predetermined number of times in a
row.
1. Is the thermistor out of order?
2. Is there any disconnected connectors or damaged
cables?
1. Replace the thermistor (After Heater). (Page 174)
2. Replace the After Heater. (Page 174)
3. Replace the Main Board. (Page 107)
1953
After Heater
heat deviation error
The difference between the current temperature and
target temperature exceeded a predetermined limit.
1. Is the thermistor out of order?
2. Is there any disconnected connectors or damaged
cables?
1. Replace the thermistor (After Heater). (Page 174)
2. Replace the After Heater. (Page 174)
3. Replace the Main Board. (Page 107)
1954
After Heater
power supply abnormal
error 1
 Cable disconnection, breaking, blowout of a fuse,
or heater failure.
 AC cable (for the After Heater) disconnection
1. Is the cable connected properly?
2. Is the Sub-E Board out of order?
3. Is the Platen Heater out of order?
1. Reconnect the cable.
2. Replace the cable.
3. Replace the Sub-E Board. (Page 115)
4. Replace the After Heater. (Page 174)
