TROUBLE SHOOTING Remedies for Service Call Error 47
Confidential
15AF
Reel Motor
lock error
 Connection failure of the Reel Motor.
 The Reel Motor was driven at a speed abnormally
slower than a predetermined one during operation.
 Irregular load
 Reel Motor encoder failure
 Reel Motor failure
1. Is there any problems such as damaged cable in the
connections below?
 Reel Motor to Sub-F Board (CN602/CN604)
2. Does the Reel Motor encoder work properly?
Check it using the Service Program.
Replace the Reel Motor. (Page 188)
1620
Pressurizing
initialization error
The initialization process did not complete within a
predetermined time period.
1. Is there any abnormal load applied to the Pressure
Unit?
2. Is there any disconnected connectors or damaged
cables?
1. Replace the Pressure Unit (IC Holder). (Page
143)
2. Replace the Main Board. (Page 107)
1621
Pressurizing/Suction
switching error
The pressurizing and suction processes did not
complete within a predetermined time period.
1. Is there any abnormal load applied to the Pressure
Unit?
2. Is there any disconnected connectors or damaged
cables?
1. Replace the Pressure Unit (IC Holder). (Page
143)
2. Replace the Main Board. (Page 107)
1622
Operating time-out
error
The switching operation did not complete within a
predetermined time period.
1. Is there any abnormal load applied to the Pressure
Unit?
2. Is there any disconnected connectors or damaged
cables?
1. Replace the Pressure Unit (IC Holder). (Page
143)
2. Replace the Main Board. (Page 107)
1623
Continuous revolution
error
The control terminal (Vre terminal) of the Pressure
Motor driver has shorted out.
1. Is the Pressure Motor driver on the Main Board
damaged?
2. Is there any foreign materials around the Pressure
Motor driver?
1. Remove the foreign material.
2. If the error still occurs, replace the Main Board.
(Page 107)
1930
Pre Heater
AD abnormal error
A thermistor temperature out of a predetermined
range was detected the predetermined number of
times in a row.
1. Is the thermistor out of order?
2. Is there any disconnected connectors or damaged
cables?
1. Replace the thermistor (Pre Heater). (Page 171)
2. Replace the Main Board. (Page 107)
1931
HTC common elements
communication error
 Connection failure between the Main Board and
Sub-E Board such as cable disconnection
 There is something wrong with the elements on the
Sub-E Board.
 There is something wrong with the communication
elements on the Main Board.
1. Is the cable connected properly?
2. Is the Sub-E Board out of order?
3. Is the Main Board out of order? (Unlikely cause of
this error)
1. Reconnect the cable.
2. Replace the cable.
3. Replace the Sub-E Board. (Page 115)
4. Replace the Main Board. (Page 107)
1932
Pre Heater
overheat error
A heater temperature out of a predetermined range
was detected the predetermined number of times in a
row.
1. Is the thermistor out of order?
2. Is there any disconnected connectors or damaged
cables?
1. Replace the thermistor (Pre Heater). (Page 171)
2. Replace the Main Board. (Page 107)
1933
Pre Heater
heat deviation error
The difference between the current temperature and
target temperature exceeded a predetermined limit.
1. Is the thermistor out of order?
2. Is there any disconnected connectors or damaged
cables?
1. Replace the thermistor (Pre Heater). (Page 171)
2. Replace the Main Board. (Page 107)
Code Error Name Cause Check Item Remedy
