SC-S30600 Series Revision B
TROUBLE SHOOTING Remedies for Print Quality Troubles 50
Confidential
Bandings in the paper feeding direction.
The Print Head has not been adjusted
properly.
---
Carry out the following adjustments.
CR Direction Head Slant Adjustment (Page
251)
PF Direction Head Slant Adjustment (Page
254)
The paper was not fed properly.
---
Carry out the following adjustment.
Feed amount adjustment
Check the following settings.
Feed Adjustment
Media Tension
PF Scale or PF Encoder failure
1. Is the PF Scale damaged or contaminated?
2. Is the PF Scale attached properly?
3. Is the PF Encoder installed correctly?
1. Clean the PF Scale.
2. Reinstall the PF Scale and PF Encoder.
3. Replace the PF Scale (Page 163) and PF
Encoder (Page 162).
The tension of the PF Timing Belt is not
proper.
---
Correct the tension of the PF Timing Belt. (Page
260)
PF Motor failure
---
Replace the PF Motor. (Page 161)
Table 2-2. Print Quality Troubles
Symptom Cause Check Item Remedy
To Next Page
