Epson SC-S60600 Series User Manual

O
Check that the air filters are installed, and then
press the Z button.
c
Important:
Make sure you install the air filters.
If the printer is used when the air filters are
not installed, sensors may degrade due to
mist causing misalignment in print and the
printer may malfunction.
P
Close the maintenance cover, and then press
the Z button.
Q
A confirmation message is displayed on the
screen. Check the content of the message, select
Yes, and then press the Z button.
Disposing of used maintenance parts U “Disposal”
on page 75
Replacing the media
edge plates
When the media edge plates supplied with the printer
are deformed or damaged, be sure to replace them
with new ones.
media edge plates available on the printer
U “Options and Consumable Products” on
page 113
c
Important:
If a deformed or damaged media edge plate
continues to be used, it may result in damage to
the print head.
Replacement procedure
A
Remove media, and turn off the printer. Check
that the screen display has turned off, and then
unplug the power cable from the outlet.
U “Removing the Take-up Roll” on page 41
Disconnect both of the power cables.
If the additional print drying system is
installed, make sure you unplug the power
cable for the additional print drying system as
well.
B
Leave the printer for a minute, and then open
the left maintenance cover and the front cover.
C
While holding the tabs of the media edge plate
on both sides, move the plate to the left edge of
the platen to remove it.
When replacing the right media edge plate,
remove the left side first, and then remove the
right.
c
Important:
Be sure to remove the media edge plate from
the left edge of the platen. If the plate is
removed from the right edge, it will drop into
the printer and cause malfunction.
SC-S80600 Series/SC-S60600 Series/SC-S40600 Series User's Guide
Maintenance
73
