Setup & Operation 2. Specifications
22 G6 Rev.21
Protected-model G6-***D/P
The following figure shows the additional parts and specifications for the Table Top
mounting Protected-model when compared with the Standard-model in appearance.
Normal G6-***D* Manipulators do not have bellows. If necessary, select the bellows
option at shipment. The following figure is a Manipulator with bellows option.
For dimensions of the end part of G6-***D* without bellows option, refer to G6-***S.
For Protected-model, all the screws used for outer parts are stainless steel screws.
(Excluding the screw used for mechanical stop.)
To Next Page
