EPSON Stylus CX7300/CX7400/DX7400/NX200/TX200 series/SX200 series/Stylus CX8300/CX8400/DX8400/NX400/TX400 series/SX400 series Revision C
PRODUCT DESCRIPTION Control Panel 25
Confidential
Start Color Normal Starts copying in color mode.
Saves the number of copies and paper type and size settings
when starting copying and displays the saved settings after the
copying is complete.
Disabled Disabled* • During printing
• During scanner operation
• During head cleaning
• During ink cartridge replacement
• When an ink error is occurring
• When print data is spooled
• When printing is being stopped or a
print job is being canceled.
Error • When a paper-out error is occurring, performs paper feed
operation. If the paper is fed successfully, cancels the error
and starts the copy job.
• When a paper jam error is occurring, performs paper
ejection operation. If the paper is ejected successfully,
cancels the error starts the copy job.
Same as the left column. Same as the left column.
Start Color
(when pressed for 3
seconds or more)
Normal Starts autofit copying in color mode.
Saves the number of copies and paper type and size settings
when starting copying and displays the saved settings after the
copying is complete.
Starts printing
according to the
DPOF setting.
Disabled*
Error • When a paper-out error is occurring, performs paper feed
operation. If the paper is fed successfully, cancels the error
and starts the copy job.
• When a paper jam error is occurring, performs paper
ejection operation. If the paper is ejected successfully,
cancels the error starts the copy job.
Same as the left column. Same as the left column.
Stop /Maintenance
+ Start Color
Normal Starts color draft copy. (A4 plain paper only)
Saves the number of copies and paper type and size settings
when starting copying and displays the saved settings after the
copying is complete.
Disabled Disabled* • During scanner operation
• During head cleaning
• During ink cartridge replacement
• When printing is being stopped or a
print job is being canceled
• When an error is occurring
Error Disabled Disabled Disabled
Table 1-20. CX7300/TX200 series Special Button Operations for Maintenance Functions
Button Function Remarks
Stop / Maintenance & Power
(Power On)
Prints a nozzle check pattern.
After printing the pattern, returns to the standby state of normal print mode.
• The nozzle check pattern printed by the printer is shown in Figure 1-11.
• If the Stop / Maintenance button is pressed while printing a nozzle check pattern, stops
printing, eject paper, and turns the power OFF.
Copies & Power
(Power On)
Enters mechanism adjustment mode and prints a Head Alignment pattern.
After printing the pattern, goes to the adjustment value input mode.
• See “ 1.7.5.8 Head Alignment ( p. 40 ) ” for details on Bi-D adjustment.
Table 1-19. CX7300/TX200 series Buttons & LEDs Functions
Button
Printer
Status
Functions
Button Operation Disabled Cases
During Normal Printing
During DPOF
Printing
During Camera Direct Printing
Note * : When in camera direct mode, starts printing according to requirements from the camera.
