123
Appendix
Appendix
Product Specifications
Printing method Thermal line printing
Cutting method Partial cut (cutting with one point in left edge left uncut)
Roll paper (single-ply) width 80 mm width paper printing: 79.5 ± 0.5 mm (3.13 ± 0.02")
58 mm width paper printing: 57.5 ± 0.5 mm (2.26 ± 0.02")
Interfaces USB: USB 2.0 Full-speed (12Mbps)
Wired LAN: 10BASE-T/100BASE-TX
Wireless LAN: Connects an optional Wireless LAN unit to the USB port.
Buffers Receive buffer 4 KB/45 bytes (selectable using DIP switch 2)
Downloaded buffer 12 KB (both for user-defined characters and downloaded images)
NV graphics data 384 KB
Web Contents Area 100 MB
Barcode/two-dimensional symbol/
composite symbol printing
UPC-A, UPC-E, JAN8 / EAN 8, JAN13 / EAN13, Code39, Code93, Code128,
ITF, CODABAR(NW-7), GS1-128, GS1 DataBar, PDF417, QR code, Maxi
Code, Data Matrix, Aztec Code, Two-dimensional GS1 DataBar,
Composite Symbology
Cash drawer function 2 drives
Power supply AC Adapter,V
Life Mechanism 20 million lines
Thermal head 200 million pulses
200 km
(when using the specified original paper types (PD160R, TF50KS-EY, or
KT55FA))
Autocutter 3 million cuts (when using the specified original paper types (PD160R,
TF50KS-EY, or KT55FA), at normal temperature and normal humidity)
MTBF 350,000 hours
MCBF 70 million lines
Temperature/humidity Operating: 5 to 45°C {41 to 113°F}, 10 to 90% RH
Storage: -10 to 50°C {14 to 122°F}, 10 to 90% RH
Overall dimensions 145 × 195 × 148 mm {5.71 × 7.68 × 5.83"} (W × D × H)
Mass Approx. 1.6 kg {3.5 lb} (roll paper excluded)
