124
Printing Specifications
dpi: dots per inch
*1: when the printer prints text (built-in fonts) with the default print density level at 24V and 25°C {77°F}.
*2: The values are those when the paper width is set to 80 mm. When it is set to 58 mm, 300 mm/s {11.8"/s}
maximum.
Printing method Thermal line printing
Dot density 180 × 180 dpi
Printing direction Unidirectional with friction feed (Reverse feed is not supported.)
Printing width 80 mm width paper printing: 72.0 mm (2.83"), 512 dots
58 mm width paper printing: 50.8 mm (2.0"), 360 dots
Characters per line Font A (12 × 24) 80 mm width paper printing: 42
58 mm width paper printing: 30
48/36 column mode: 48
Font B (9 × 17) 80 mm width paper printing: 56
58 mm width paper printing: 40
48/36 column mode: 53
Kanji Font A 80 mm width paper printing: 21
58 mm width paper printing: 15
Kanji Font B 80 mm width paper printing: 32
58 mm width paper printing: 22
Special Font A 80 mm width paper printing: 42
58 mm width paper printing: 30
48/36 column mode: 40
Special Font B 80 mm width paper printing: 56
58 mm width paper printing: 40
48/36 column mode: 53
Maximum print speed*
1
350 mm/s*
2
Line spacing 4.23 mm {1/6"} (Default value, programmable by command)
Print speed may be slower, depending on such items as the data transmission speed.
