Arranging the Cables
Route the cables when using the connector cover.
Pass the cables through cable exits in the connector cover. The connector cover has cable exits on the back and
both sides.
You can also route the cables out the front by passing them through the notch in the printer bottom.
When using cables without lock, use of the bundled cable lock band is recommended.
You can also attach bottom cover to hide connectors.
Make sure the cable does not get caught when installing.
