Electrical Characteristics
AC Adapter,V Input voltage AC 100-240V
Rated frequency 50-60Hz
Supply current from the product USB port with charging function 2.1A
Power consumption
(AC100-230 V / 50-60 Hz)
Operating 27.4W
Standby 1.5W
Continuously printing high coverage data may activate the over-current protection. Make sure to
configure so that print length of high-coverage print does not exceed the values described below.
If the over-current protection activates due to high coverage prints, uneven print density or a low
voltage error will result.
Because the total amperage can exceed the amperage rating, do not charge a device such as
tablet while using DM-D210 and OT-WL05.
Print ratio 80% 100%
Print example
Print length 30 mm 20 mm
