Epson TM-U295 User Manual

EPSON
TITLE
SHEET
REVISION
NO.
SHEETNEXT
F
TM-U295/U295P
Specification
(STANDARD)
45 44
ESC
*
**
*
m n
L
n
H
d1...dk
[Name] Select bit-image mode
[Format] ASCII ESC
*
n
L
n
H
d1...dk
Hex 1B 2A
n
L
n
H
d1...dk
Decimal 27 42
n
L
n
H
d1...dk
[Range]
m
= 0, 1
0
£
n
L
£
255
0
£
n
H
£
3
0
£
d £
255
k
=
n
L
+
n
H
´
255
[Description] Selects a bit-image mode m for the number of dots specified by
n
L
and
n
H
, as follows:
ù
The nL and nH indicate the number of dots of the bit image in the horizontal direction.
The number of dots is calculated by the formula
n
L
+
n
H
´
256.
ù
If the bit-image data input exceeds the number of dots to be printed on a line, the
excess data is ignored.
ù
d
indicates the bit-image data. Set a corresponding bit to 1 to print a dot or to 0 to not
print a dot.
ù
Bit image modes which can be selected by m are shown in the table below.
Vertical Direction Horizontal Direction(*1)
m
Mode
Number of Dots Dot Density Dot Density
Maximum
Number of Dots
0
8-dot single-
density
8 60 DPI 80 DPI 210
1
8-dot double-
density
8 60 DPI 160 DPI 420
*1: The number of dots in the horizontal direction depends on the printing area and the
printing direction specified by
ESC W
and
ESC T
.
[Notes]
ù
If
m
and
n
H
is out of the specified range, the data following
n
L
is processed as normal
data.
ù
After the bit image is printed, the printer returns to the normal data processing routine.
ù
The relationship between bit image data and dots to be printed is given on the next
page.
ù
In page mode, double density bit image data is not available.
[Reference] Section 3.9,
Page Mode

Epson TM-U295 Specifications

General

Color	No
Maximum number of copies	2 copies
Maximum printing width (columns)	42
Dimensions (WxDxH)	180 x 190.5 x 101.5 mm
Power requirements	24 VDC±10%
Connectivity technology	Wired
Printing media thickness	0.09/0.35 µm
Mean time between failures (MTBF)	180000 h
Safety	UL, CSA C22.2 No. 950
Country of origin	Japan
Electromagnetic compatibility	VCCI class A, FCC class A, CE marking
Pallet width	1200 mm
Pallet height	1000 mm
Pallet length (UK)	1370 mm
Quantity per pallet	120 pc(s)
Quantity per pallet (UK)	160 pc(s)
Master (outer) case width	300 mm
Quantity per pallet layer	24 pc(s)
Master (outer) case height	405 mm
Master (outer) case length	485 mm
Harmonized System (HS) code	84433210
Quantity per pallet layer (UK)	32 pc(s)
Quantity per master (outer) case	4 pc(s)
Package depth	270 mm
Package width	235 mm
Package height	185 mm
Package weight	1845 g
Quantity per pack	1 pc(s)

Weight and Dimensions

Depth	191 mm
Width	180 mm
Height	102 mm
Weight	1600 g
