Epson VT6L

Maintenance 8. Cable
VT Rev.1 155
(31)
Pass
the ground wire and the following cables of each arm
through the sleeve of
each joint and pull them out.
Ground wires × 4
Signal cables (for motor × 5)
LED cable × 1
(32)
Pass
the power cable through the sleeve of each joint and pull it out in the following
order.
Arm #4 → Arm #3 → Arm #2 → Arm #1 → Base
