eqss Gen-3 LMS - Installation Index

Installation Index
The components and cables of the Gen-3 Telehandler Load Management System are
outline in the tables below. The following pages show where the components are installed
and the cable routing.
See the appropriate manual section for a detailed installation description for each
component.
Refer to this section for any component placement or cable
routing issues
Item Component Description
1 Cable Reeler
2 Main Lift Cylinder Pressure Sensors
3 Compensation Cylinder Pressure Sensors
4 Can Pressure Input Module (CPIM)
5 Cutout Connection
6 Lock Pin Release Connection
7 Forward Camera
8 Signal Light
Table 1: Component Installation Index
DO001547 VER: 2303241610 6 of 58
