Step Description Diagram
6. Scroll to the next page and select
Save to store the new time/date and
return to the Advanced Menu.
7. Select Sensor Calibrations
8. Select Calibrate Carrier Angle and
then follow the instructions on the
screen to complete the calibration.
Repeat for Calibrate Boom Angle and
Calibrate Boom Length.
Table 17: Sensor Calibration
