Signal Light Installation
The signal light warns other workers when the telehandler is lifting loads close to it's
maximum capacity.
otherwise the signal light may not illuminate correctly.
Step Description Diagram
1. Mount the signal light to the top of
the cabin using the magnetic anchor.
View from on top of the cabin
2. Inside the cabin, remove the roof
cover behind the seat leading to the
joystick.
View from drivers seat to the roof
DO001547 VER: 2303241610 23 of 58
