Step Description Diagram
5. Operate the boom movement
controls to test if a false N07 fault
occurs.
If a N07 fault does occur, adjust
the arm on the stow switch
forwards towards the stow switch
trigger.
Note: The actual switch arm
orientation may differ from the
picture.
6. Perform a final check on all the
cabling and sensors.
Replace all the covers
Table 16: Finalisation
completed.
