eqss Gen-3 LMS - Set Time & Sensor Calibration

Set Time & Sensor Calibration
Once the installation is complete, the time will need to be set and the sensors will require
calibration.
Step Description Diagram
1. Press Enter on the user control dial
to enter the menu system.
Press the arrow buttons to select
System Menu.
Press Enter to select the menu.
2. Select Advanced Menu
DO001547 VER: 2303241610 45 of 58
A sensor calibration must be performed once the cable reeler
and CPIM have been mounted. If the cable reeler or CPIM
have been moved/repositioned a recalibration must be
performed
