ERS
®
Manual / AirCool
®
plus
-System / SP72_TA1C8 / -55°C +200°C / Ver. 02.02 9
3.3 System specifications
3.3.1 Operating conditions
Operating conditions
Ambient temperature +18°C to +28°C
Relative humidity 20% to 60%
Mains supply 100/ 115/ 200/ 230V
50/ 60Hz
450VA Controller SP72
1500VA Chiller 03
1950VA System total
Compressed air
Air supply max. 310 l/min recommended
Air pressure 6 bar (0.6Mpa, 87 PSI)
Compressed air dew point ≤ -45°C
Compressed air temperature ≤ +26°C
Compressed air purity 99.9% apply to 3 µm
Residual oil volume 0.01mg/ m
3
apply to 20°C and 7 bar
Square requirement
Controller SP72 19" rack
483mm x 144mm x 326mm
Chiller 03 422mm x 933mm x 490mm
caution
To meet the specifications the following operating
conditions must be followed.
If specifications for compressed air purity are not met,
serious damage may occur to the chuck.
