10 IEEE-488 Interface (Optional)
10.1 Setting the IEEE-Address
After switching on the SP72 controller shows the IEEE-Address on the display panel.
The temperature display shows "IEEE" and the set temperature display shows the
actual IEEE-Address. To change the address follow the oncoming procedure.
ÿ switch off the controller
ÿ press the * key and hold it down while switching on the controller
ÿ release the * key when the LED inside the "Enter" key starts to flash
ÿ the controller is in setup mode now
ÿ it shows IEEE in the left display and the address in the right display
ÿ press enter and the address will start to flash
ÿ now you can enter a new address in the range from 0 to 31 using the numeric
keypad
ÿ end the procedure by pressing the "Enter" key
ÿ to leave the setup mode press the * key
The new address is now stored in the controller's nonvolatile memory.
10.2 IEEE 488 Communication Capabilities
Supported Interface Functions
SH1 Source Handshake Capability
AH1 Acceptor Handshake Capability
T8 Basic Talker
L4 Basic Listener
RL1 Remote / Local Capability
DC1 Device Clear Capability
SR0 No Service Request
PP0 No Parallel Poll
DT0 No Device Trigger
