SOFTWARE UPDATE
0740 801 028
- 59 -
© ESAB AB 2017
Supported commands
Commands supported by “reset.txt” are:
• General reset
• Set machine id
• Set baudrate
• Set node address (node id).
Each command are represented by a set of numbers in a text line written into “reset.txt”.
NOTE!
General reset will delete all saved data in the unit, the node adress will be set to
8 and the baudrate will be set to 400kbit/s.
General reset
Line Comment
4 0 0 1 0 0
General reset.
Will delete all saved data in the unit.
Node adress set to 8.
Baudrate set to 400kbit/s.
Set machine id
Line Comment
29 0 0 44 0 255
Set the machine id to 44 (PEK).
29 0 0 460 255
Set the machine id to 46 (PAB).
Set baudrate
Line Comment
28 0 0 0 0 255
Set CAN bus bauderate to 1000 kbit/s.
28 0 0 1 0 255
Set CAN bus bauderate to 800 kbit/s.
28 0 0 2 0 255
Set CAN bus bauderate to 500 kbit/s. Normal setting for the PEK.
28 0 0 3 0 255
Set CAN bus bauderate to 250 kbit/s.
28 0 0 4 0 255
Set CAN bus bauderate to 125 kbit/s.
28 0 0 5 0 255
Set CAN bus bauderate to 100 kbit/s.
28 0 0 6 0 255
Set CAN bus bauderate to 50 kbit/s.
28 0 0 7 0 255
Set CAN bus bauderate to 20 kbit/s.
28 0 0 8 0 255
Set CAN bus bauderate to 10 kbit/s.
28 0 0 9 0 255
Set CAN bus bauderate to 400 kbit/s.
Set node adress (node id)
Line Comment
30 0 0 8 0 255
Set the node address to 8, use for (PEK and PAB unit).
