Escea DS1400 - C2 Flue Configuration (for more than 4 M Length)

B
A C D E F G SERVICE
14
C2 Flue Configuration (If more than 4m flue length is required):
If your flue system is greater than 4m long (as shown in diagrams below), then a flexible flue with
condensate trap and rigid PP tube flue lengths is required.
FOR MORE INFORMATION ON
INSTALLATION OF THE POLYPRO
FLUE, SEE ‘POLY PRO FLUE
INSTALLATION INSTRUCTIONS’
AVAILABLE ON:
WWW.ESCEA.COM
OR SUPPLIED WITH THE FLUE.
FOR POLY PRO COMPONENT GUIDES,
THESE ARE AVAILABLE ON:
WWW.ESCEA.COM
TITLED:
HORIZONTAL FLUE COMPONENT
GUIDE &
VERTICAL FLUE COMPONENT GUIDE
4m
Ø80mm / Ø100mm
Flexible Flue
1.2m Co-axial Flue
Vertical Powerue
12m MAX
Ø100mm
Condensate Trap
Ø80mm / Ø100mm
PP Tube
ESCEA WALL
TERMINAL
Ø80mm / Ø100mm
PP Tube
Ø100mm
Condensate Trap
Ø80mm / Ø100mm
Flexible Flue
4m
12m MAX
