C3 Installing the Horizontal Powerflue Wall Terminal option
The Horizontal Powerflue Wall Terminal must be installed in the
correct orientation. This allows for the correct operation of the flue
system and prevents the ingress of water.
The Horizontal Powerflue Wall Terminal must be weather-tight when
installation is complete to prevent damage to the dwelling. It must be
installed by a suitably qualified person.
Fit the Horizontal Powerflue Wall Terminal into the hole and fix in place, making sure the installation is
sealed appropriately to prevent the ingress of water from outside the wall cladding. Take notice of the
label on the termination which shows the correct orientation that the terminal should be fitted.
NOTE: It is the responsibility of the installer to ensure the Horizontal Powerflue Wall Terminal is
installed to all relevant building codes to ensure weather tightness.
