24
FOR MORE INFORMATION ON INSTALLATION OF THE POLYPRO FLUE, SEE ‘POLY
PRO FLUE INSTALLATION INSTRUCTIONS’ AVAILABLE ON:
WWW.ESCEA.COM
OR SUPPLIED WITH THE FLUE.
FOR POLY PRO COMPONENT GUIDES, THESE ARE AVAILABLE ON:
WWW.ESCEA.COM
TITLED:
HORIZONTAL FLUE COMPONENT GUIDE &
VERTICAL FLUE COMPONENT GUIDE
C8 Running the Powerflue Electrical Cable
Note: The Powerflue Terminal is powered from the appliance, and must be connected to the appliance with
the supplied electrical cable only.
Note: Ensure that the appliance power supply is disconnected before making the connection to the terminal
The supplied electrical cable is 7m long, flue extension kits also include a powerflue electrical cable
extension.
Run the electrical cable from the cavity where the appliance will be installed to the hole in the outside
wall. Ensure it is not draped over, or in contact with, the outer shell of the appliance or the flues and
kept clear from any other possible heat sources, sharp edges, or moisture. Fix it appropriately and allow
enough cable looped to be able to pull both the appliance and the powerflue terminal out from their
installed positions.
END OF SECTION C
By the end of this section, you should have:
□ A weather-tight installed Powerflue Terminal with clearance as specified by AS/NZ5601
□ Reasonable access to the terminal for maintenance purposes
□ Flue attached to the Powerflue Terminal leading back to the appliance with the correct
flue clearances
□ The electrical cable from the Powerflue Terminal run back to the appliance cavity in an
electrically safe manner
