2: Auto-demo run.
• Auto-demo mode is used for demonstrating the operation or commissioning in the factory.
There is no need to be controlled by the control system. The auto-demo mode can be set after
door machine’s operation curve is set. The interval time between open and closed door demo
can be set by P6.04.
• To start auto-demo run by pressing / key or closing external terminals OD / CD with
COM.
• To stop auto-demo run by pressing key.
Define the maximum allowed output frequency of controller.
After input the advanced password, you can check the advanced parameters. In generally, it need not
check the advanced parameters. But if needed, you can contact the manufacture to get the advanced
password.
0: Asynchoronous motor open-loop distance control.
1: Asynchoronous motor closed-loop distance control.
2: Synchoronous motor closed-loop distance control.
4.2 Group P1 Motor Rated Parameters
Code Name Description Range
factory setting
P1.00 Motor rated power 1
750W
250W
P1.02 Motor rated current 0.10
10.00A
1.10A
P1.04 Motor rated Rpm 1
6000rpm
180rpm
Correctly set the parameters according to the rated parameters of motor nameplate.
• To ensure the control performance, the motor power should match that of the controller.
• For asynchronous motor, the setting value of P1.01 should be the asynchronous rated voltage of
motor nameplate.
• For synchronous motor, the setting value of P1.01 should be the inverter rated voltage, which is
220V. Do not set the value of P1.01 as the synchronous motor’s nameplate rated voltage,
otherwise the motor will not run normally.
P1.05 Deceleration ratio 1.00
9.99
1.00
For the KS door machine, this value is 1.00.
For the MS door machine it need input the correct value according to the actual situation. For the
small shaft 25mm diameter, it need input 5.60; For the big shaft 30mm diameter, it need input 4.67.
Generally if the open door width does not exceed 1950mm, it will be called as small shaft.
P1.06 Motor parameter auto-tuning 0,1
0
0: No action.
1: Motor auto-tuning.
• Before auto-tuning, it must input correct motor parameters as per its nameplate.
• When set P1.06 as 1, it starts motor parameter auto-tuning. When it is completed, P1.06 will auto
become to zero.
