SuZhou Eshine Elevator Components Co., Ltd. Chapter 3 Operation Instructions
YS-K01 Door Controller User Manual ―15―
The YS-P02 panel has 5 state and 5 unit indicators and their meanings are shown as Table 3-6.
Table 3-6 Indicator description of YS-P02
Identification
Name Description
OD run state
indicator
ON: The present controller is in OD state
OFF: The present controller is not in OD state
CD run state
indicator
ON: The present controller is in CD state
OFF: The present controller is not in CD state
Warning state
indicator
ON: The present controller is faulty
OFF: The present controller is not faulty
Remote/local state
indicator
ON: The present controller is not in panel control mode
OFF: The present controller is in panel control mode
Password lock state
indicator
ON: The user password of present controller is enabled
OFF: The present controller has no password or is at unlock
state
Frequency unit
indicator
ON: The present unit is Hz
OFF: The present unit is not Hz
Current unit
indicator
ON: The present unit is A
OFF: The present unit is not A
Voltage unit
indicator
ON: The present unit is V
OFF: The present unit is not V
Rpm unit indicator
ON: The present unit is rpm
OFF: The present unit is not rpm
Percentage unit
indicator
ON: The present unit is %
OFF: The present unit is not %
The indicator has two states off and on. In the manual the identification is as follows:
The indicator is off; The indicator is on.
3.2.1 Display State of YS-P02 Panel
The controller parameters can be displayed via using the optional YS-P02 panel. The display
state of panel of controller has stopping state, running state, editing state and alarming state.
Display parameter at stopping state
When controller stops running, the panel will display parameter at stopping state, as shown in
Figure 3-14. By pressing key to display other stopping parameters: door position pulse,
OD/CD arrival signal (OD pulse arrival, OD torque arrival, CD pulse arrival, CD torque arrival),
setting frequency, input terminal state and DC bus voltage.
Figure 3-14 YS-P02 display at stopping state
Hz
A V RPM %
REVFWD ALM LO/RE LOCK
