SuZhou Eshine Elevator Components Co., Ltd. Chapter 5 Controller Debugging
YS-K01 Door Controller User Manual ―49―
5.9.2 Debugging Steps
Step 1:
For the no updated product, according to the motor’s model the controller parameters
can be reset by pressing one key! Refer to parameter P0.01 for more details.
Example: If the motor nameplate current is 1.10/1.35A, it means that this is synchronous motor.
My company has only one synchronous motor specification, and you can directly set P0.01=3,
then it will reset the synchronous motor parameters.
If the motor nameplate current is 0.95/0.55A, it means that this is asynchronous 70W motor,
directly set P0.01=11 and press the key to reset the 70W asynchronous parameters;
If the motor nameplate current is 1.95/0.90A, it mean that this is asynchronous 150W motor,
directly set P0.01=13 and press the key to reset the 150W asynchronous parameters;
For the asynchronous parameters the Dec ratio P1.05 is defaulted as 4.67, but some may be set
according to the situation. Refer to appendix A for more details.
For the updated product, the controller parameters can be reset by pressing one key. Refer to
parameter P8.10 for more details.
For more convenience of customers to debug, Eshine has system customized the normal OD
parameters of KS series and MS series and input V1.04 software version to the controller and the
panel. The user only need set one parameters to use the function. The debugging mode is shown
as Table 5-1.
Table 5-1 Debugging mode
Series Specifications
With the latest panel or the controller (with one will be fine)
YS-P02 or YS-P03 Controller with V1.04 and above
KS series
KS centre
opening 800
P8.10=11 P8.10=01
KS centre
opening 900
P8.10=12 P8.10=02
MS series
MS centre
opening 800
P8.10=13 P8.10=03
MS centre
opening 900
P8.10=14 P8.10=04
MS side opening
1100
P8.10=15 P8.10=05
MS side opening
1200
P8.10=16 P8.10=06
Step 2:
To start motor auto-tuning, set P0.06=0 and P1.06=1, then press or key. Refer
to 5.1 for motor parameter auto-tuning.
Step 3:
To start door width self-learning, set P2.05=1, then press or key, the door
machine will do “open door- closed door- open door- closed door”. The door width will be stored
to P2.06 and P2.07 at the end of self-learning. Refer to 5.2 for door width self-learning.
